Multi Blades Block Cutting Machine

Name: Multi Blades Block Cutting Machine
Brand: StoneSawMachine.com
Price: 1 USD

Brand Name : StoneSawMachine.com

Model Number : MCQSJ-2500

Certification : ISO9001

Place of Origin : China

MOQ : 1 Set

Price : Negotiable

Payment Terms : L/C, , T/T

Supply Ability : 20 Sets Per Month

Delivery Time : 30 days after deposit

Packaging Details : Plastic FIlm

Voltage : 380/220/415V

Weight : 17000kg

Use : granite and marble

Condition : New

Dimension(l*w*h) : 7500*4500*7000mm

Type : Stone Cutting Machine

Warranty : One Year

Control system : PLC SYSTEM

Product name : Multi Blades Block Cutting Machine

Color : customized

Motor : AC Servo System

Application : Stone Industrial

Spindle : 55kw

Blade diameter : 2800mm

Function : STONE CUTTING,marble/granite edge cutting machine

Keyword : Stone cutting machine

Contact Now

MULTI-BLADES DOUBLE HYDRAULIC BLOCK CUTTER BTC-2200/2500/2800/3000 uses inverter to control left-right feeding adjusts the speed according to the stone material. It uses hydraulic lifting system(screw lifting system*optioal), forward-backward slicing uses high-precision screw nut driving, automatic slicing, main spare parts adopt imported good-quality materials. The block can be placed in the ground directly to save worktable and its maintenance costs. Thus the whole machine is featured as high cutting efficiency, high slicing precision, flatness of plate after cutting, high stability, easy-operating to suit specially cutting granite and marble block with high value.

Specifications:

Model	DTQZ-2200-4D	DTQZ-2600-4D	DTQZ-2800-4D
Max. Blade Diameter	2200mm	2600mm	2800mm
Max. Cutting Length	3200mm	3200mm	3200mm
Max. Cutting Height	2200mm	2200mm	2200mm
Max. Cutting Depth	950mm	1150mm	1250mm
Max. Lifting Distance	1220mm	1320mm	1400mm
Water Consumption	15m3/h	15m3/h	15m3/h
Main Motor Power	37kW	45kW	55kW
Total Power	50kW	58kW	68kW
Dimension	750045006800mm	750045006800mm	750045007000mm
Weight	16000kg	16500kg	17000kg

Multi Blades Block Cutting Machine
